Once a prime number has been chosen for the number of
vertices, the circle must be divided into that many equal divisions. This
is done with the dividers, or a compass, and is the most critical step
in drawing an accurate template. Start by calculating the distance between
points by dividing the circumference of your circle by the number of vertices
you desire. Set the distance of your dividers to equal this distance and
walk them around the circle. Walking the dividers set at this calculated
distance around the circle will tell you how close your initial setting
is to the exact one. Ideally, traveling once around the circle should bring
the point of the dividers right back to the first mark. This rarely happens
on the first trial, but repeated adjustments of the divider setting will
lead eventually to an equidistannt set of points,
The circumference "C" of a circle
with radius r is given by
C = 2 pie r~ 6.3r.
When the correct setting is found,
each indicated point should be marked on the template, as shown above.
Check to make sure the total number of marks is equal to the number expected!
It's easy to leave one out or add one extra without noticing. After the
divisions are marked and double checked, the template is finished.
THREADING A CIRCULAR DESIGN:
The theory of threading a Mandala
geometric thread design is simpler than most people realize.
Basically, the threading of each
layer involves nothing more than counting a certain number of points between
connected points. In the design being started in the picture above, there
are 53 brass pins located at the vertices.
Of the (53 - 1)/2 = 26 possible
circular layers, that one which results in the second smallest circle is
being started. Thus after tying the thread at an arbitrary starting point,
it is wound around the 25th pin (counting clockwise). Counting in the same
direction another 25 pins brings the thread to the next point to be connected,
and this process is continued until all the pins have been connected and
the first layer is completed. This brings the thread back to the starting
point where it is tied off.
