Spray Ball of static heads (Cleaning
ball)
[SB - P]:
Application:
The spray ball with static head is a fixed sprinkler capable for washing with chemical solutions or water, especially all types of recipients under the C.I.P. system (clean in place).
This system considerably optimizes the cleaning, guaranteeing, according to appropriate technical specifications, the superficial cleaning of the totality of the containing element, reducing the operative time of work and care of the personnel it replaces, giving a service of total aptitude, suitable and provable efficacy.
The haul it produces by pressure generates a total superficial cleanup and favors the work as it reduces time in the procedure of cleanup, and not using the personnel with products that could be generators of inconveniences.
|
Models and Dimensions (mm) |
| Model (position m) | d1 | d2 | d3 | Ø perforation (m3) |
| SB - mS1 - 2251 - F - qt | 20,2 (0,795 inch) | 22,2 (0,874 inch) | 50,8 (2 inch) | 1,75 (0,067 inch) (1) |
| SB - mS1 - 2851 - F - qt | 26,6 (1,047 inch) | 28,6 (1,126 inch) | 50,8 (2 inch) | 1,75 (0,067 inch) (1) |
| SB - mSL - 2863 - F - qt | 26,6 (1,047 inch) | 28,6 (1,126 inch) | 63,5 (2,5 inch) | 2,5 (0,099 inch) (L) |
| SB - mSL - 3263 - F - qt | 29,7 (1,169 inch) | 31,7 (1,248 inch) | 63,5 (2,5 inch) | 2,5 (0,099 inch) (L) |
| SB - mSL - 3863 - F - qt | 36,1 (1,421 inch) | 38,1 (1,5 inch) | 63,5 (2,5 inch) | 2,5 (0,099 inch) (L) |
| SB - mSL - 3801 - G - qt | 35,7 (1,406 inch) | 38,1 (1,5 inch) | 101,6 (4 inch) | 2,5 (0,099 inch) (L) |
| SB - mSK - 4214 - G - qt | 39,8 (1,567 inch) | 42,2 (1,661 inch) | 114,3 (4,5 inch) | 2,0 (0,079 inch) (K) |
Características de la información Adicional:
| Model (position m1): (type of perforation) | ||||
| T | Total | |||
| S | Superior | |||
| L | Lateral | |||
| I | Inferior | |||
| General Width: | ||||
| F | 1,0 mm (0,039 inch) | |||
| G | 1,2 mm (0,047 inch) | |||
| Quality (position q): | ||||
| 4 | AISI 304/304L | |||
| 6 | AISI 304/304L | |||
| Surface Finishing (position t): | ||||
| B | Brilliant, Mirror | |||
| M | Dull, unpolished | |||
| Ø Ball hole (position m3): | ||||
| 1 | 1,75 mm (0,069 inch) | |||
| K | 2,0 mm (0,079 inch) | |||
| L | 2,5 mm (0,098 inch) | |||
Spray Ball with státic head (cleaning ball) [SB-P]:
Application:
The spray ball with static head is a fixed sprinkler capable for washing with chemical solutions or water, especially all types of recipients under the C.I.P. system (clean in place).
This system considerably optimizes the cleaning, guaranteeing, according to appropriate technical specifications, the superficial cleaning of the totality of the containing element, reducing the operative time of work and care of the personnel it replaces, giving a service of total aptitude, suitable and provable efficacy.
The haul it produces by pressure generates a total superficial cleanup and favors the work as it reduces time in the procedure of cleanup, and not using the personnel with products that could be generators of inconveniences.
|
Models and Dimensions (mm) |
| Model | d1 | d2 | d3 | Ø Ball hole | Ø hole tube (m3) |
| SB - PA1 - 2251 - F - qt | 20,2 (0,795 inch) | 22,2 (0,874 inch) | 50,8 (2 inch) | 1,75 (0,067 inch) (1) | 1,75 (0,067 inch) (1) |
| SB - PA1 - 2851 - F - qt | 26,6 (1,047 inch) | 28,6 (1,126 inch) | 50,8 (2 inch) | 1,75 (0,067 inch) (1) | 1,75 (0,067 inch) (1) |
| SB - PA1 - 2863 - F - qt | 26,6 (1,047 inch) | 28,6 (1,126 inch) | 63,5 (2,5 inch) | 2,5 (0,099 inch) (L) | 1,75 (0,067 inch) (1) |
| SB - PB1 - 2863 - F - qt | 26,6 (1,047 inch) | 28,6 (1,126 inch) | 63,5 (2,5 inch) | 2,5 (0,099 inch) (L) | 1,75 (0,067 inch) (1) |
| SB - PB1 - 3263 - F - qt | 29,7 (1,169 inch) | 31,7 (1,248 inch) | 63,5 (2,5 inch) | 2,5 (0,099 inch) (L) | 1,75 (0,067 inch) (1) |
| SB - PCK - 3263 - F - qt | 29,7 (1,169 inch) | 31,7 (1,248 inch) | 63,5 (2,5 inch) | 2,5 (0,099 inch) (L) | 2,0 (0,079 inch) (K) |
| SB - PCK - 3863 - F - qt | 36,1 (1,421 inch) | 38,1 (1,5 inch) | 63,5 (2,5 inch) | 2,5 (0,099 inch) (L) | 2,0 (0,079 inch) (K) |
| SB - PDK - 3863 - F - qt | 36,1 (1,421 inch) | 38,1 (1,5 inch) | 63,5 (2,5 inch) | 2,5 (0,099 inch) (L) | 2,0 (0,079 inch) (K) |
| SB - PDK - 3801 - G - qt | 35,7 (1,406 inch) | 38,1 (1,5 inch) | 101,6 (4 inch) | 2,5 (0,099 inch) (L) | 2,0 (0,079 inch) (K) |
| SB - PEK - 3801 - G - qt | 35,7 (1,406 inch) | 38,1 (1,5 inch) | 101,6 (4 inch) | 2,5 (0,099 inch) (L) | 2,0 (0,079 inch) (K) |
| SB - PEL - 3801 - G - qt | 35,7 (1,406 inch) | 38,1 (1,5 inch) | 101,6 (4 inch) | 2,5 (0,099 inch) (L) | 2,5 (0,099 inch) (L) |
| SB - PEL - 4214 - G - qt | 39,8 (1,567 inch) | 42,2 (1,661 inch) | 114,3 (4,5 inch) | 2,0 (0,079 inch) (K) | 2,5 (0,099 inch) (L) |
| SB - PFL - 4214 - G - qt | 39,8 (1,567 inch) | 42,2 (1,661 inch) | 114,3 (4,5 inch) | 2,0 (0,079 inch) (K) | 2,5 (0,099 inch) (L) |
| SB - PGL - 4214 - G - qt | 39,8 (1,567 inch) | 42,2 (1,661 inch) | 114,3 (4,5 inch) | 2,0 (0,079 inch) (K) | 2,5 (0,099 inch) (L) |
Characteristics of additional information:
| Model (position m1): (type of perforation) | ||||
| T | Total | |||
| S | Superior | |||
| L | Lateral | |||
| I | Inferior | |||
| General Width: | ||||
| F | 1,0 mm (0,039 inch) | |||
| G | 1,2 mm (0,047 inch) | |||
| Quality (position q): | ||||
| 4 | AISI 304/304L | |||
| 6 | AISI 304/304L | |||
| Surface Finishing (position t): | ||||
| B | Brilliant, Mirror | |||
| M | Dull, unpolished | |||
| Ø hole tube (position m3) and Spray ball: | ||||
| 1 | 1,75 mm (0,069 inch) | |||
| K | 2,0 mm (0,079 inch) | |||
| L | 2,5 mm (0,098 inch) | |||
Fasteners of quick clousure [CR]:
Application:
These types of fasteners are essential to hold elements of stainless steel under pressure. The same came be used in an internal way, and with the friction of the product it may be making, as also used externally; because of its fine finishing it is fit for c’GMP standards, and its resistant design allows to make the most demanding tests keeping under security.
It also counts with the option of adding to its traditional design and the new one fit for using the safety gadget, so it becomes essential in the airtight closure of the products that require no environmental contamination and the safety/security of its controlled opening (with a safety gadget of numbered safety).
The variation of the receptors and its three types make this fastener cover the majority of the needs of closure, air tightness and safety that the industries need today, mainly the pharmacological, medicinal and food need to guarantee their products and care of the same.
Each of the three modalities:
|
Fixed: |
||
| Normal Standard |
CR - FJN - cccc - G - qt |
|
| To use safety gadget | CR - FJP - cccc - G - qt | |
|
Regulable: |
||
| Normal Standard |
CR - REN - 060c - G - qt |
|
| To use safety gadget | CR - REP - 060c - G - qt | |
| With shooter: | ||
| Normal Standard |
CR - TIN - cccc - G - qt |
|
| To use safety gadget | CR - TIP - cccc - G - qt | |
Characteristics of additional information:
| Long rod with closure (position c123): | ||||
| 040 | 40 mm (1,575 inch) of useful length | |||
| 060 | 60 mm (2,362 inch) of useful length | |||
| 080 | 80 mm (3,150 inch) of useful length | |||
| Types of shooters (position c4): | ||||
| A | Normal width | |||
| B | Normal Standard | |||
| C | Double shirt | |||
| General Width: | ||||
| F | 1,0 mm (0,039 inch) | |||
| G | 1,2 mm (0,047 inch) | |||
| Quality (position q): | ||||
| 4 | AISI 304/304L | |||
| 6 | AISI 304/304L | |||
| Surface Finishing (position t): | ||||
| B | Brilliant, Mirror | |||
| M | Dull, unpolished | |||
| Important: | ||||
|
The quantities are considered grouping only the same standard types or to be used with the safety gadget..- |
||||
Aplication:
Casquetes Semi- spherical, which are habitually used for the endings of pipes, in elements of decoration, stairs, etc.
|
Models and Dimensions (mm) |
| Model | Ø | h |
| CA - STD - 050A - e - qt | 50,8 (2 inch) | 25,4 (1 inch) |
| CA - STD - 050B - e - qt | 50,8 (2 inch) | |
| CA - STD - 063A - e - qt | 63,5 (2,5 inch) | 31,7 (1,248 inch) |
| CA - STD - 063B - e - qt | 63,5 (2,5 inch) | |
| CA - STD - 101A - e - qt | 101,6 (4 inch) | 50,8 (2 inch) |
| CA - STD - 101B - e - qt | 101,6 (4 inch) | |
| CA - STD - 114A - e - qt | 114,3 (4,5 inch) | 57,1 (2,248 inch) |
| CA - STD - 114B - e - qt | 114,3 (4,5 inch) |
Characteristics of the additional information:
| General width (position e): | ||||
| G | 1,2 mm (0,047 inch) | |||
| I | 1,5 mm (0,059 inch) | |||
| K | 2 mm (0,079 inch) | |||
|
Quality (position q): |
||||
| 4 | AISI 304/304L | |||
| 6 | AISI 304/304L | |||
| Surface Finishing (position t): | ||||
| B | Brilliant, Mirror | |||
| M | Dull, unpolished | |||
| S | No polish | |||
Application:
This key is to use with screws built under Danish norms starting from 1” (25.4 mm) to 4” (101.6 mm). Consult for screws of other norms.
|
Model |
| CA - STD - 0104 - T - qt |
Characteristics of the additional information:
| General width (position e): | ||||
| T | 1/4 inch or 6 mm | |||
|
Quality (position q): |
||||
| 4 | AISI 304/304L | |||
| 6 | AISI 304/304L | |||
| Surface Finishing (position t): | ||||
| B | Brilliant, Mirror | |||
| M | Dull, unpolished | |||
Industrial Paper Roll Supports - APB - [PR]:
Application:
As can be appreciated in the photo, it is useful for rolls of paper to up to 250 mm of Ø.
The cutting of the paper is made with a double dented safe system, allowing it to be easily separated, even with paper of double thickness.
The loading and removal of the paper is made with a spring blocking system that it has in both ends, that also serve as protection to avoid the roll accidentally falling.
Its termination and format makes it apt for pharmacological, medicinal, food and other industries, as it is not only useful under c’GMP standards but also practical to be cleaned.
| Model |
| PR - APB - 250c - N - qt |
Characteristics of the additional information:
| Model (position c4): | ||||
| P | To fix to the wall | |||
| B | With a reinforced base | |||
| General width : | ||||
| N | 3 mm (0,118 inch) | |||
|
Quality (position q): |
||||
| 4 | AISI 304/304L | |||
| 6 | AISI 304/304L | |||
| Surface Finishing (position t): | ||||
| B | Brilliant, Mirror | |||
| M | Dull, unpolished | |||
Slots
for Folders - (wall supported)
- [SL]:
Application:
These slots are totally open and are used mostly in industries where it is demanded that there be no possibility of cleaning the place easily. They are designed to be supported to walls, wall divisors, allowing to hang the folders and/or portfolios Rivadavia size.
| Model |
| SL - STD - RIVA - R - qt |
Características de la información Adicional:
| General width : | ||||
| R | 5 mm (0,197 inch) | |||
|
Quality (position q): |
||||
| 4 | AISI 304/304L | |||
| 6 | AISI 304/304L | |||
| Surface Finishing (position t): | ||||
| B | Brilliant, Mirror | |||
| M | Dull, unpolished | |||
Other types of serial Works, in stages of study and testing -[XX]:
Application:
As there are various elements in development stage (and in each type there are variants), and though some are about to be regulated, and others are very advanced, we can indicate that they are all designed to reach the complete satisfaction of the final user.
If you are interested in being notified immediately when we have these elements designed, please do not doubt in sending us your request in our mail, and we will be glad to inform you.
Among the same, the following items are being made:
