Kevin's Solar Imaging Page

Last Update - July 18, 2004

SOLAR IMAGES USING HERSCHEL WEDGE

Most of the images that I took on this page before 2001 are mostly made with Canon EOS-50E SLR camera coupled to my TV-101, a 101mm f/5.4 apo-flourite refractor. But since then, I had been using a Nikon Coolpix 995 digital camera together with my TV-101 refractor to image the ever changing face of Earth's nearest star, the SUN. You can see the various faces of the Sun which I was able to image on my free time, mostly during morning of weekends . I have divided them into two sections, namely HIGH RESOLUTION and WHOLE DISK.

HIGH RESOLUTION:

AR 0652 - Image taken on July 18, 2004 using Canon EOS 300D at 15,500mm f/154 at 1/4000 sec at ISO 100.

PREVIOUS IMAGES: (Click image for better view)

AR 0649 - Image taken on July 18, 2004 using Canon EOS 300D at 15,500mm f/154 at 1/4000 sec at ISO 100.

AR 0570 - Image taken on March 8, 2004 using Canon EOS 300D at 15,500mm f/154 at 1/4000 sec at ISO 100.

AR 0564 - Image taken on February 28, 2004 using Canon EOS 300D at 15,500mm f/154 at 1/4000 sec at ISO 100.

AR 0486 - Image taken on November 3, 2003 using Canon EOS 300D at 15,500mm f/154 at 1/4000 sec at ISO 100. This sunspot group resembled or shaped like a pregnant Seahorse or baby fetus :) LOL

AR 0488 - Image taken on November 3, 2003 using Canon EOS 300D at 15,500mm f/154 at 1/4000 sec at ISO 100.

AR 0488 (top) and 0486 (bottom) - Image taken on November 3, 2003 using Canon EOS 300D at 4,300mm f/43 at 1/4000 sec at ISO 100.

AR 0486 - Image taken on November 2, 2003 using Canon EOS 300D at 15,500mm f/154 at 1/4000 sec at ISO 100.

AR 0488 (top) and 0486 (bottom) - Image taken on November 2, 2003 using Canon EOS 300D at 4,300mm f/43 at 1/4000 sec at ISO 100.

AR 0488 - Image taken on November 2, 2003 using Canon EOS 300D at 15,500mm f/154 at 1/4000 sec at ISO 100.

AR 0486 - Image taken on October 26, 2003 using Canon EOS 300D at 15,500mm f/154 at 1/4000 sec at ISO 100.

AR 0484 - Image taken on October 26, 2003 using Canon EOS 300D at 15,500mm f/154 at 1/4000 sec at ISO 100.

AR0375 - Image taken on June 11, 2003 using CP995 at 17,100mm f/170 at 1/250 sec at ISO 100.

AR0380 - Imaged on June 11, 2003 using CP995 att 17,100mm f/170 at 1/125 sec at ISO 100.

AR0343 (left) and AR 0344 (right) - Imaged on April 27, 2003 using CP995 at 17,100mm f/170 at 1/125 sec at ISO 100.

AR0349 (left), AR0345 (center) and AR 0347 (right) - Imaged on April 27, 2003 using CP995 at 17,100mm f/170 at 1/125 sec at ISO 100.

AR0114 (left) and AR 0105 (right) - Imaged on September 15, 2002 using CP995 at 17,100mm f/170 at 1/500 sec at ISO 100.

AR0095 - Imaged on September 3, 2002 using CP995 at 17,100mm f/170 at 1/125 sec at ISO 100.

AR0095 - Imaged on September 1, 2002 using CP995 at 17,100mm f/170 at 1/125 sec at ISO 100.

AR0087 - Imaged on September 1, 2002 using CP9995 at 17,100mm f/170 at 1/500 sec at ISO 100.

AR0085 - Imaged on August 25, 2002 using CP995 at 17,100mm f/170 at 1/125 sec at ISO 100.

AR0087 - Imaged on August 25, 2002 using CP995 at 17,100mm f/170 at 1/125 sec at ISO 100.

AR0083 (Left) and AR0088 (Right) - Imaged on August 25, 2002 using CP995 at 17,100mm f/170 at 1/125 sec at ISO 100.

AR0069 - Imaged on August 20, 2002 using CP995 at 17,100mm f/170 at 1/30 sec at ISO 100.

AR0085 - Imaged on August 20, 2002 using CP995 at 17,100mm f/170 at 1/125 sec at ISO 100.

AR0069 - Imaged on August 19, 2002 using CP995 at 17,100mm f/170 at 1/125 sec at ISO 100.

AR0079 - Imaged on August 19, 2002 using CP995 at 17,100mm f/170 at 1/60 sec at ISO 100.

AR0085 - Imaged on August 19, 2002 using CP995 at 17,100mm f/170 at 1/250 sec at ISO 100.

AR0039 (top) and AR 0044 (bottom) - Imaged on July 28, 2002 using CP995 at 17,100mm f/170 at 1/250sec at ISO 100.

AR0050 - Imaged on July 28, 2002 using CP995 att 17,100mm f/170 at 1/500sec at ISO 100.

AR0039 (top) and AR 0044 (bottom) - Imaged on July 27, 2002 using CP995 at 17,100mm f/170 at 1/500sec at ISO 100.

AR0045 - Imaged on July 27, 2002 using CP995 att 17,100mm f/170 at 1/250sec at ISO 100.

AR0043 - Imaged on July 27, 2002 using CP995 att 17,100mm f/170 at 1/500sec at ISO 100.

AR0036 - Imaged on July 27, 2002 using CP995 att 17,100mm f/170 at 1/250sec at ISO 100.

AR0036 - Imaged on July 23, 2002 using CP995 att 17,100mm f/170 at 1/250sec at ISO 100.

AR0039 - Imaged on July 23, 2002 using CP995 att 17,100mm f/170 at 1/250sec at ISO 100.

AR0030 - Imaged on July 17, 2002 using CP995 att 17,100mm f/170 at 1/250sec at ISO 100.

AR0036 - Imaged on July 17, 2002 using CP995 att 17,100mm f/170 at 1/250sec at ISO 100.

AR0019 - Imaged on June 30, 2002 using CP995 att 17,100mm f/170 at 1/125sec at ISO 100.

AR0008 - Imaged on June 30, 2002 using CP995 at 17,100mm f/170 at 1/125sec at ISO 100.

AR9991 - Imaged on June 9, 2002 using CP995 at 17,100mm f/170 at 1/250sec at ISO 100.

AR9987 - Imaged on June 9, 2002 using CP995 at 17,100mm f/170 at 1/500sec at ISO 100.

AR9985 - Imaged on June 9, 2002 using CP995 at 11,725mm f/116 at 1/1000sec at ISO 100.

AR9978 / 9973 - Imaged on June 5, 2002 using CP995 at 11,725mm f/116 at 1/1000sec at ISO 100.

AR9978 - Imaged on June 5, 2002 using CP995 at 17,100mm f/170 at 1/250sec at ISO 100.

AR9973 - Imaged on June 5, 2002 using CP995 at 17,100mm f/170 at 1/250sec at ISO 100.

AR9973 - Imaged on May 30, 2002 using CP995 at 17,100mm f/170 at 1/250sec at ISO 100.

AR9957 - Imaged on May 19, 2002 using CP995 at 17,100mm f/170 at 1/250sec at ISO 100.

AR9948 - Imaged on May 19, 2002 using CP995 at 17,100mm f/170 at 1/250sec at ISO 100.

AR9767 - Imaged on December 31, 2001 using CP995 at 17,100mm f/170 at 1/125sec at ISO 100.

AR9755 - Imaged on December 31, 2001 using CP9995 at 17,100mm f/170 at 1/250sec at ISO 100.

AR9690 - Imaged on November 11, 2001 using CP9995 at 17,100mm f/170 at 1/250sec at ISO 100.

AR9682 - Imaged on November 1, 2001 using CP995 at 11,725 f/116 at 1/60sec at ISO 100.

AR9415 - Imaged on April 8, 2001 at 14,625mm f/145 at 1/4000sec with Fujichrome Provia 100 film.

AR 9393 - Image on March 25, 2001 at 11,700mm f/116 at 1/4000sec with Kodak Technical Pan film.

AR ???? - Imaged on December 30, 2000 at 7,800mm f/77 at 1/4000sec with Fujichrome Provia film.

WHOLE DISK:

The Sun - Imaged on July 18, 2004 using Canon EOS 300D at 1760mm f/17 at 1/4000sec at ISO 100.

PREVIOUS IMAGES: (Click image to get better view)

The Sun - Imaged on March 8, 2004 using Canon EOS 300D at 1760mm f/17 at 1/4000sec at ISO 100.

The Sun - Imaged on February 28, 2004 using Canon EOS 300D at 1760mm f/17 at 1/4000sec at ISO 100.

The Sun - Imaged on November 3, 2003 using Canon EOS 300D at 1760mm f/17 at 1/4000sec at ISO 100.

The Sun - Imaged on November 2, 2003 using Canon EOS 300D at 1760mm f/17 at 1/4000sec at ISO 100.

The Sun - Imaged on October 30, 2003 using Canon EOS 300D at 1760mm f/17 at 1/4000sec at ISO 100.

The Sun - Imaged on October 26, 2003 using Canon EOS 300D at 1760mm f/17 at 1/4000sec at ISO 100.

The Sun - Imaged on June 11, 2003 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on April 27, 2003 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on September 15, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on September 3, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on September 1, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on August 25, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on August 20, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on August 19, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on July 28, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on July 27, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on July 23, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on July 17, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on June 30, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on June 9, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on June 5, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on May 30, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on May 19, 2002 using CP995 at 2350mm f/23 at 1/2000sec at ISO 100.

The Sun - Imaged on December 31, 2001 using CP995 at 2350mm f/23 at 1/1000sec at ISO 100.

The Sun - Imaged on November 11, 2001 using CP995 at 2350mm f/23 at 1/500sec at ISO 100.

The Sun - Imaged on November 1, 2001 using CP995 at 2350mm f/23 at 1/1000sec at ISO 100.

The Sun - Imaged on April 8, 2001 at 1782mm f/17 at 1/4000sec with Fujichrome Provia Film.

The Sun - Imaged on March 25, 2001 at 1782mm f/17 at 1/1000sec with Kodak Technical Pan Film.

The Sun - Imaged on December 30, 2000 at 1782mm f/17 at 1/4000sec with Fujichrome Provia Film.

The Sun - Imaged on September 24, 2000 at 1782mm f/17 at 1/1000sec with Fujichrome Provia Film.

The Sun - Imaged on January 30, 2000 at 1782mm f/17 at 1/4000sec with Fujichrome Provia Film.
