SPECIFICATIONS:

Display Type Multi-Media Monitor
Display Area 36.2½(W) x 20.4½(H)
Display resolution 852 x 480 pixels
(Number of Pixels)
Color System NTSC/PAL/SECAM/NTSC4.43/
PAL-M/PAL-N
Computer Compatibility Up to SXGA 1280 x 1024
Brightness 780 cd/m2 for set
(typ. white peak)
Contrast ratio 4000 : 1 (typ)
Amplifier Digital Amp. 10W+10W RMS
(Speakers : Optional)
Dimensions 40.23½(W) x 24.01½(H) x 3.3½(D)
(without Handle)
Set Weight 66.13 Lbs.
(without Table Top Stand and Speaker)
Package Single Carton
Packed Dimensions 49.37½(W) x 31.45½(H) x 18.3½(D)
Packed Weight 79.36 Lbs.
Rating Power Supply 120V AC, 50/60Hz
Power Consumption 308W
AC Power Cord Detachable Type

TERMINALS:

PC INPUT
Signal Dsub-15
Audio Stereo Mini
RS232C Input
Serial Dsub-9
Wired Remote Control IN Stereo Mini
RS232C Output
Serial Dsub-9
Wired Remote Control Out Stereo Mini
EXT. Speaker OUT Push Type

STANDARD INTERFACE: (included)

INPUT-1
Signal Input RCA(Video), DIN4PIN(S-Video)
Audio Input RCAx2
INPUT-2
Signal Input RCA(Video), DIN4PIN(S-Video)
Audio Input RCAx2
INPUT-4
Signal Input RCAx3(Y, Pb/Cb, Pr/Cr)
Audio Input RCAx2

OPTIONAL INTERFACES: (not included)

Optional Interface Board Model# VB-4230-DVI
Signal Input-1 DVI-D (with HDCP)
Signal Input-2 BNC(Video), DIN4PIN(S-Video)
Audio Input RCAx2
Optional Interface Board Model# VB-4230-RGB
Signal Input-1 BNCx5(R,G,B,H,V and Y, Pb/Cb, Pr/Cr)
Signal Input-2 BNC(Video), DIN4PIN(S-Video)
Audio Input RCAx2

REGULATIONS AND CONDITIONS:

cUL
Safety cUL(UL6500)
Emissions FCC/DOC ClassA
Operating Temperature 0 to 40(Degree Centigrade)
Storage Temperature -10 to 50(Degree Centigrade)
Operating Humidity 20 to 80 (%)
Storage Humidity 10 to 90 (%) (No condensation)

ACCESSORIES:

O/Manual (3 languages : English, French, Spanish)
Remote Control (with Battery)
Wired RC Cable
AC Cord

CONTROLS:

Plasma Display Unit
Power Turn ON/OFF
OK/Input Go to next/Mode Select
Vol UP/DN, Right/Left Volume UP/DN, Cursor Right/Left
UP/DN Cursor UP/DN
Menu Picture Setup, Sound Setup,
PC Mode Adjustment,System Setup
Time Setup, Timer Setup

REMOTE CONTROL:

POWER ON-OFF Turn ON/OFF
INPUT Select Input
WIDE Change wide mode
PICTURE Change picture settings
MENU Pop up Menu
VOLUME +/ RIGHT Volume up
VOLUME -/ LEFT Volume down
UP(MOVE UP)
DOWN(MOVE DOWN)
BACK Return
OK
MUTE Audio mute
STATUS Recall current status
ON-OFF PIP ON/OFF
LOCAT PIP location
SIZE PIP size
2-WIN PAP(Side by side) ON/OFF

OPTIONS:

Table top stand Model# ELE4230-DS
29.4½(L) x 12.6½(W)
Wall mount unit Model# ELE4230-SM
Tilt mount unit Model# ELE4230-PRO
Speakers Model# SP-4230-LR
3.7½(W) x 20.74½(H) x 3.42½(D)

REVIEW THESE SPECS.

• Aspect Ratio: Widescreen 16:9
• Diagonal Screen Size: 42 in
• Resolution: 852 x 480, supports , up to 1280 x 1024 scaled, up to UXGA (automatic frequency detection), including the following standard: VGA, SVGA, XGA, SXGA, UXGA
• Included Features: PIP and Side by Side
• Contrast: 4000:1 Contrast Ratio
• Display Type: Plasma Display
• Output: A/V (RCA Composite)
• Mounting: Desktop, Wallmount
• Height: 24"
• Width: 40.2"
• Depth: 3.3"
• Weight: 66 lbs
• Warranty 1 year(s)
