Imperial Japanese Naval Dive Bomber PAGE

2001 / 1 / 10 Update.


Aichi D4Y1 "Suisei" Model 11 Dive Bomber (Judy)
Length : 10.22m
Wing Span: 11.50m
Hight : 3.295m
Wing Area : 23.6 Square Meter
All-Up Weight : 3,960Kg
Empty Weight : 2,440Kg
Main Engine : Aichi Atsuta 21 (1,200hp) X 1
Max Speed : 552Km/h
Cruse Speed : 426Km/h
Max Range : 2,590Km
Service Ceiling : 9,900m
Crew : 2
Armament : 7.7mm Machine Gun X 1, 7.7mm Slewing Machine Gun X 1
Bomb : 250Kg X 1 or 500Kg X 1 or 60Kg X 2
Aichi D4Y3 "Suisei" Model 33 Dive Bomber (Judy)
Length : 10.22m
Wing Span: 11.50m
Hight : 3.74m
Wing Area : 23.6 Square Meter
All-Up Weight : 3,754Kg
Empty Weight : 2,501Kg
Main Engine : Mitsubishi Kinsei 62 (1,560hp) X 1
Max Speed : 574Km/h
Cruse Speed : 333Km/h
Max Range : 2,911Km
Service Ceiling : 10,500m
Crew : 2
Armament : 7.7mm Machine Gun X 2, 7.7mm Slewing Machine Gun X 1
Bomb : 250Kg X 3
