| Vintage Sears Garden Tractors |
| Suburbans |
| Sears updated their Suburban tractors in the mid 60's. Gone were the Bradley transmissions. They were replaced by a conventional transaxle. A standard clutch/brake pedal and gear shift replaced the F/N/R lever on the old tractors. A built in High/Low range eliminated the extra cost and complexity of adding a speed reducer. Tecumseh engines replaced the Briggs models installed in the earlier Suburbans. The horsepower race had begun. The Briggs engine would later return, along with a twin cylinder Onan. The front mounting attachment points were left the same as the old Suburbans : four holes on the axle and a slide in channel frame. The rear drawbar was now a slanted piece of formed steel mounted to the frame behind the transmission. The mounting pin for the lower lift arms of the 3-point hitch passed through the drawbar on these tractors. A heavier model of 3-point hitch became available as horsepower and pulling ability increased. A Super model was introduced, which included such upgrades as cigarette lighter, chrome wheel covers and wider tires. The designation Super can be traced back many years to the David Bradley walking tractor line. Tractors also used the model names of SS or ST, followed by the horsepower rating of the tractor. Variations on the Suburban theme would continue, with increased power being the most notable trend. Most were basically the same tractor design, with minor changes to the engines, grill and dash. Click on the links below to see pictures of the tractors. ** In 1976, Sears began to sell what they labeled a garden tractor, which was produced by the Murray Company. They were called ST/8 and ST/10 in 1977, model numbers 502.25900 and 502.25910. These machines were not made by the Roper Company and are not included in this database. ** |
| Hi, welcome to Spence's Vintage Sears Garden Tractor site. I saw a need for this information after many people asked what year their Sears Tractor was made. With that in mind, I set off on a mission to gather as much information as I could and to present it here in this public forum for all to use. I hope you enjoy your visit here. Please be sure to visit the homepage if you were directed here from a link on someone else's site. I'm working hard to provide more Sears information all the time. If you have something you think is relevant, please let me know. I hope you bookmark my site and return often. |
 |
 |
 |
| 917.99400 Recoil 917.99410 Electric 917.99420 917.25100 Recoil 917.25110 Electric 917.25120 917.25340 917.25350 917.25310 917.25520 917.25510 917.25550 917.25510 917.25610 917.25370 917.25200 917.25380 917.25730 917.25740 917.25750 917.25730 917.25740 917.25750 917.25860 917.25870 917.25880 917.25930 917.25940 917.25950 917.25960 917.25170 917.25180 917.25190 917.257050 917.257060 917.257080 917.257110 917.257080 |
| Note that the images hosted on this site are intended to be used for educational or reference purposes only. Owners of Sears tractors often are interested in what year their tractor was manufactured. Also of interest to owners are the color schemes and decals originally applied to the tractors. It is the hope of the owner of this site that the images may be of use to those interested in restoring their tractors to their original condition or who are merely curious as to when they were made. This site is strictly non-profit in nature. The funds used to purchase the material on E-Bay and to host this site are contributed by the site owner at his personal expense. |
|
|
|
|
|
