June 2001:
The Alokistocare / Amecephalus / Altiocculus problem:
Amecephalus packi, Upper Glossopleura Zone, Chisholm Shale, Lincoln
Co. Nevada
photo courtesy Andrew Milner
Amecephalus cf. packi, Upper Glossopleura Zone, Chisholm Shale, Lincoln
Co. Nevada
photo courtesy Andrew Milner
Amecephalus piochensis, Upper Glossopleura Zone, Chisholm
Shale, Lincoln Co. Nevada
photo courtesy Andrew Milner
Altiocculus
drumensis, Upper Wheeler Shale Formation, Millard Co., Utah
left photo courtesy Andrew Milner, right Kevin D. Brett
The relationships of Cambrian ptychopariid trilobites
are poorly known and difficult to determine based mainly on generalized
and convergent morphologies of this group of trilobites. Alokistocaridae
Resser 1939 is no exception to this. To date, over 85 species have been
assigned to the genus Alokistocare Lorenz 1906, of which 56 are
still valid (Sundberg, 1999). This was due, in part, to the poorly known
morphology of the type species, A. subcoronatum (Hall and Whitfield,
1877). Howell (in Harrington et al., 1959) assigned 30 genera to Alokistocaridae
Resser 1939, only a few of which have been reassigned to other families.
For those collectors with North American species
of Alokistocare, you may want to check the species below to see
if they have been reassigned to different genera. Although the list is
far from complete, for those interested in further information, please
use the references listed at the end.
A recent phylogenetic analysis by Sundberg (1999) using a matrix of 50 characters and 19 taxa resulted in the following conclusions:
1. Alokistocaridae Resser 1939 is a monophyletic
clade (and is not synonomous with Papyriaspididae Whitehouse 1939)
2. Ehmaniellidae Sundberg 1994 is synonomous with
Alokistocaridae
3. Pseudoalokistocare Sundberg, 1994 is
synonomous with Alokistocare
4. Taxa previously assigned to the older "Alokistocare"/Amecephalus
group (Plagiura to Glossopleura biochrons) form a separate
clade from both Alokistocare and the Alokistocaridae. These older
species are assigned to Amecephalus Walcott 1924
Alokistocare is restricted to the Marjuman Stage
Amecephalus is restricted to the Delamaran Stage (Eokochaspis
nodosa biozone to Glossopleura Biozone)
Strotocephalus Resser, 1935 = Amecephalus
Genera included in the Alokistocaridae (by Sundberg, 1999) are: Alokistocare, Altiocculus, Ehmaniella, Elrathiella, Proehmaniella and probably Schopfaspis. Genera previously assigned to Ehmaniellidae, including Ehmania, Elrathia, Parehmania, Pseudomexicella, Trachycheilus, and Tympanuella may also belong to Alokistocaridae.
Amecephalus differs from Alokistocare in that it has a poorly developed occipital ring and furrow; poorly defined anterior border furrow; strap-like posterior area of the fixigena; and a pygidium with poorly defined anterior pleural bands that do not project from the border area.
Alokistocare includes the type species, A. subcoronatum (Hall and Whitfield, 1877), A. swasii, A. paranotatum, and others.
Amecephalus includes the type species, A. piochensis (Walcott, 1886), A. arrojosensis (Lochman, 1952), A. agnesensis (Walcott, 1912), A. cleora (Walcott, 1917), A. gordonensis (Resser, 1935), A. laticaudatum, A. idahoense, A. packi, and others.
Altiocculus includes A. concavus, A. drumensis, A. harrisi, A. americanus, and others.
The systematics of this family is complicated and attempts to classify the trilobites into various subfamilies has not been widely adopted. Although this recent cladistic study resolves the relationships of some alokistocarid species, it does not tackle a revision of all species formerly assigned to Alokistocare.
References:
Sundberg, F. A. (1999) Redescription of Alokistocare subcoronatum (Hall and Whitfield, 1977), the type species of Alokistocare, and the status of Alokistocaridae Resser, 1939b (Ptychopariida: Trilobita, Middle Cambrian). Journal of Paleontology, Vol. 73, no. 6, pp. 1126-1143.
Sundberg, F. A. and McCollum, L. B. (2000) Ptychopariid trilobites
of the Lower-Middle Cambrian boundary interval, Pioche Shale, southeastern
Nevada. Journal of Paleontology, Vol. 74, no. 4, pp. 604-630.
