ENGINE, ELECTRICAL SYSTEM
Type 4 cyl - 5V Effective displacement (cc) 1781 Cylinder borestroke (mm) 81 x 86,4 Compression ratio 9,5 Maximum power (kw(hp)/rpm) 115/156 / 5800 Maximum torque (Nm/rpm) 210/1800 - 2200 Fuel supply system Multipoint Injection Integral electronic ignition TURBO Fuel type 95 NO Accelerator control EGAS Emission control
Alternator (A) 70/90 Battery (Ah/A) 60/280
PERFORMANCES
Maximum speed (km/h) 218 Acceleration 0-100 km/h (s) 7,9 Acceleration 60-100 km/h (s) 10,5 Acceleration 1000 m (s) 28,4
FUEL CONSUMPTION
City driving (l/100 km) 10,8 Extracity driving (l/100 km) 6,0 Ponderable consumption (l/100 km) 7,8
TRANSMISSION
Gearbox type: 02J.A
Development:
3,300 II 1,944 III 1,308 IV 1,029 V 0,837 R 3,060 Reduction group 3,389 Speed 1000 rpm in V (km/h) 37,20
SUSPENSION
Front Independent type McPherson, with inferior triangle with uncouple softering dock.
Stabilizing bar diameter 18 mm for 1.4l 44kw/60hp; 20 mm for 1.6l 55kw/75hp,
1.6l 74kw/100hp, 1.4l-16V, 1.9 SDi, 1.9 TDi 66kw/90hp and 1.9 TDi 81kw/110hp.
Special 21,7 for 1.8 20 VT and (1.4l 74kw/100hp + 1.6l 74kw/100hp) in Sport Rear Directional effect shaft, suspension longitudinal arms. Stabilizing bar for 1.8 20VT
+ 1.9 TDi (66kw/90hp and 81kw/110hp) + 1.4 74kw/100hp + 1.6 74kw/100hp in Sport Steering system Rack and pinion. Power steering standard (optional 1.0/1.4 44kw/60hp in Select/Stella) Turning diameter (m) 10,9 Brake system Diagonally split, twin circuit, brakes servo. ABS optional. ABS. EDS. /TCS for 1.9 TDi
81kw/110hp and 1.8 20VT 115kw/156hp Types brakes front/rear Selfvent. Disc/Disc Brakes front (mm) 280 x 22 Brakes rear (mm) 232 x 9
WHEELS
Rim 16" Tyres 195/45 R16
DIMENSIONS
Type 3 or 5 doors Length/width/height (mm) 3877/1640/1422 Wheel base (mm) 2443 Track, front/rear (mm) 1429/1394 Boot capacity (l) 250/560/782 (According to Norms V210/V212/V214) Petrol tank capacity (l) 45
WEIGHT
In running order without driver (kg) 1119 Maximum weight (kg) 1579 Maximum weight with brake (kg) 1000
