Position |
Value |
Manufacturer |
|
BR101, BR102 |
5A |
Any diode bride 5A or more |
|
|
|
|
|
C1 |
410 pF |
Silver Mica SSG-1 |
|
C2 |
0.22μF 600V |
Hovland Musicap |
|
C3, C4 |
100+100μF 500V |
Black Gate WKZ |
|
C5 |
0.01μF 400V |
Silver Mica SSG-1 |
|
C6 |
3300 pF |
Silver Mica SSG-1 |
|
C7, C8 |
0.22μF 400V |
0.22μF TFT Relcap + Silver Mica
SSG-1 3600pf |
|
C101, C103 |
220μF 160V |
Black Gate NH |
|
C102, C104 |
820 μF 200V |
Nichicon GK |
|
C105 |
68μF 350V |
Black Gate NH |
|
C106 |
100+100μF 500V |
Black Gate WKZ |
|
C107, C110 |
100μF 16v |
Any |
|
C108, C111 |
1μF 16v |
Any |
|
C109, C112 |
23000μF 16v |
Mallory |
|
|
|
|
|
F101, F102, F103 |
1A 250V |
Any slow fuse |
|
|
|
|
|
Ic101, Ic102 |
LM338T |
Any |
|
|
|
|
|
R1 |
20K 0,5W |
Tantalum |
|
R2 |
100K 2W |
Tantalum |
|
R3 |
2M 0,5W |
Tantalum |
|
R4, R5 |
120 K 1W |
Tantalum |
|
R6 |
600 Ώ 0,5W |
Tantalum |
|
R7 |
33k 1W |
Tantalum |
|
R8, R9, R10, R101, R102 |
3.3K 1W |
Tantalum |
|
R11, R12 |
1.0 M 0.5W |
Tantalum |
|
R13, R103 |
2.2K 1W |
Tantalum |
|
R104, R105, R108, R109 |
470ohm 1W |
Any |
|
R106, R110 |
120ohm 0,5W |
Any |
|
R107, R111 |
500ohm 1W |
Any potentiometer |
|
|
|
|
|
T1 |
8920 |
Sowter, UK |
|
T2 |
8650 |
Sowter, UK |
|
T101 |
263AX |
Hammond |
|
T102 |
272DX |
Hammond |
|
T103 |
185D16 |
Hammond |
|
|
|
|
|
VT1, VT3 |
6922 |
|
|
VT2 |
6188 |
|
|
Vt101, Vt102 |
5AR4 |
|
|
|
|
|
|
Steel Chassis |
1441-8 |
Hammond |
|
Speaker spikes |
DSS4 |
Dayton |
