leichter Munitionspanzerwagen Sd.Kfz.250/6
Ausf A - für Sturmgeschütz 7.5cm Kanone (Kurz) Ausf A bis E
Ausf B - für 7.5cm Sturmgeschütz 40 Ausf F und G

Sd.Kfz.250/6 Ausf A was an ammunition carrier attached to Stug III units armed with short 75mm guns. It carried 70 rounds of ammunition - 2 rounds in each of the 35 boxes. Ausf A was discontinued in 1942, when Stug IIIs were armed long 75mm guns. Sd.Kfz.250/6 Ausf B was a modified version of Ausf A to accomodate the bigger ammunition used by Stug III Ausf F and Gs. It carried 60 rounds of ammunition. Ausf A and B were introduced to replace leichte Gepanzerte Munitionskraftwagen Sd.Kfz.252 ammunition carriers. Internal stowage of both variants varied to suit layout. On Ausf B, the vision window on the right hand side differed from that of the basic vehicle.

Specifications

Weight:	5950kg (Ausf A) 6090kg (Ausf B)
Crew:	2 men
Engine:	Maybach HL42TRKM / 6-cylinder / 100hp
Speed:	Road: 60km/h Cross-Country: --km/h
Range:	Road: 320km Cross-Country: ---km
Fuel Capacity:	--- litres
Lenght:	4.56m
Width:	1.95m
Height:	1.66m
Armament:	7.92mm MG34 (Ausf A) 7.92mm MG34 or MG42 (Ausf B)
Ammo:	7.92mm - 2010 rounds
Armor:	6-14.5mm
