Arnet Pereyra Aero Design
of Rockledge, Florida, USA produces theBeaudry Aviation
Home of the
Aventura II
Arnet Pereyra Aero Design
of Rockledge, Florida, USA produces the
Aventura line of light single and two-seat amphibians. This plane's design
and construction use the same materials and design concepts as many
current ultralight designs. The airframe of this kit consists of aircraft
quality aluminum tubing and fittings bolted together using aircraft-grade
fasteners. The wing and control surfaces are covered with heavy-
duty dacron cloth, much like what is used with boat sails. The hull of this
this plane is fiberglass, standard, with Kevlar as an option to save weight.
Light, fun and affordable- that's what the Aventura is all about.
| FIBERGLASS HULL/DECK 6061 T-6 ANODIZED ALUMINUM 12 GAL. FUEL TANK FIXED RUDDER TRIM BRS VLS 1200 PARACHUTE |
TWO COLOR DACRON FABRIC AIRSPEED INDICATOR EGT GAUGE RPM GAUGE ALTIMETER COMPASS |
DETACHABLE WINGS QUICK FOLD TAIL BILGE PUMP ELECTRIC FLAPS HOUR METER BRAKES |
ELEVATOR TRIM WATER TEMP. GAUGE RADIATOR COWLING (582/618) OIL TEMP. GAUGE (912) OIL PRESSURE GAUGE (912)
|
Click on individual image to enlarge.
Builder assist programs available for the Aventura
Experimental Amphibian plane. For more info, contact:
Phillip Beaudry
Beaudry Aviation/Newport State Airport (EFK)
2628 Airport Road - Coventry
Newport, VT 05855
Phone/Fax: (802) 334-5001
E-Mail: beaudryaviation@yahoo.com
To locate airport, click here.
PERFORMANCE |
DESCRIPTION |
UL ROTAX 447 |
HP ROTAX 503 |
HP ROTAX 582 |
AVII ROTAX 582 |
AVII ROTAX 618 |
AVII ROTAX 912 |
AVII ROTAX 912 ULS |
| ENGINE HORSEPOWER | 40 |
52 |
65 |
65 |
75 |
79/81 |
90/100 |
| CRUISE SPEED, (MPH) | 55 | 75 | 75 | 70 | 70 | 75 | 80 |
| TOP SPEED, (MPH) | 63 | 85 | 90 | 90 | 90 | 90 | 90 |
| NEVER EXCEED SPEED, VNE | 70 | 90 | 90 | 90 | 90 | 90 | 90 |
| STALL SPEED FULL FLAPS, (MPH) | N/A | 28 | 32 | 32 | 32 | 32 | 32 |
| STALL SPEED NO FLAPS, (MPH) | 28 | 32 | 40 | 45 | 45 | 42 | 42 |
| TAKE OFF DISTANCE: LAND/WATER, (FT.) | 150 | 150 | 150 | 200 | 200 | 150 | 150 |
| RATE OF CLIMB; VY, (FPM) | 500 | 700 | 1400 | 500 | 550 [EST] | 700 | 1100 |
| ENDURANCE | 1.5 HOURS | 2.5 HOURS | 2.5 HOURS | 2.5 HOURS | 2.5 HOURS | 3.5 HOURS | 4 HOURS |
| SERVICE CEILING, (FT.) | 13,500 | 13,500 | 13,500 | 13,500 | 13,500 | 13,500 | 13,500 |
| LENGTH | 20'6" | 20'6" | 20'6" | 23' | 23' | 23' | 23' |
| WINGSPAN | 27'8" | 29'8" | 29'8" | 30'8" | 30'8" | 30'8" | 30'8" |
| HEIGHT | 6' | 6' | 6' | 7' | 7' | 7' | 7' |
| WING AREA, (SQ. FT.) | 156 | 156 | 156 | 161.7 | 161.7 | 161.7 | 161.7 |
| CONSTRUCTION TIME, (HRS.) | 80 | 90 | 90 | 200 | 200 | 225 | 225 |
| EMPTY/GROSS WEIGHT | 328/650 | 390/750 | 430/950 | 650/1200 | 650/1200 | 750/1350 | 750/1350 |
