CB/HAM RADIO TRANSCEIVERS
Alignment Information
| MC | ALC | AM Power | MOD Meter | RF Meter | AM S- Meter | SSB S- Meter | AM Squelch | SSB Squelch | USB Freq | LSB Freq | AM Freq | TX Freq | Radio Model |
| - | - | L3,6 | - | VR6 | VR5 | - | VR2 | - | - | - | - | TC1 | TRC 414 |
| VR By Q9 | - | VI By Final | - | VR By Final | RV1 | - | RV3 | - | - | - | - | CT1 | TRC 415 |
| - | - | L1 | - | VR1 | VR2 | - | VR3 | - | - | - | - | TC1 | TRC 417 |
| - | - | L3 | - | VR1 | VR2 | - | VR3 | - | - | - | - | TC1 | TRC 418 |
| VR202 | - | L305 | - | VR By D105 | VR By C500 | - | VR By R563 | - | - | - | - | C514 | TRC 419 |
| - | - | L104 L106 | - | - | VR4 | - | VR3 | - | - | - | - | CT1 | TRC 420 |
| - | - | L12 | - | VR6 | VR5 | - | VR2 | - | - | - | - | CT1 | TRC 421 |
| - | - | L12 | - | VR6 | VR5 | - | VR2 | - | - | - | - | CT1 | TRC 422 |
| - | - | L12 | - | - | VR5 | - | VR2 | - | - | - | - | CT | TRC 422A |
| RV202 | - | L305 L306 | - | RV301 | RV101 | - | RV201 | - | - | - | - | VC By 515 | TRC 423 |
| VR9 | - | L909 | - | VR7 | VR4 | - | VR6 | - | - | - | - | ??? | TRC 424 |
| VR8 | - | L905 | - | VR11 | VR3 | - | VR5 | - | - | - | - | CT801 | TRC 425 |
| VR8 | - | L901 L903 | - | VR11 | VR3 | - | VR5 | - | - | - | - | CT801 | TRC 426 |
| VR5 | - | L12 | - | VR4 | VR3 | - | VR2 | - | - | - | - | VC1 | TRC 427 |
| - | - | L5,8 | - | VR8 | VR3 | - | VR6 | - | - | - | - | - | TRC 428 |
| RV104 | - | L306 L307 | - | RV106 | RV By C132 | - | RV By Q208 | - | - | - | - | CT201 | TRC 430 |
| VR7 | - | L910 | - | VR5 | VR4 | - | VR3 | - | - | - | - | - | TRC 431 |
| VR4 | - | L9,12 | - | VR3 | VR1 | - | VR2 | - | - | - | - | - | TRC 435 |
| - | - | L102 L104 L106 | - | - | VR6 | - | VR4 | - | - | - | - | CT1 | TRC 440 |
| - | - | L104 L107 | - | VR1 | VR3 | - | VR5 | - | - | - | - | CT1 | TRC 441 |
| VR5 | VR204 | VR210 | - | VR203 | VR205 | - | VR209 | - | - | - | - | ??? | TRC 448 |
| VR6 VR7 | CT7 | VR8 | - | VR12 | VR1 | - | VR3 | - | - | - | - | ??? | TRC 449 |
| VR5 | VR6 | VR10 | - | VR7 | VR1 | - | VR2 | - | L20 | L21 | L19 | VR3 | TRC 451 |
| VR207 | - | L212 | - | VR206 | VR205 | - | VR204 | - | - | - | - | VC1 | TRC 452 |
| VR5 | VR6 | VR10 | - | VR7 | VR1 | - | VR2 | - | L16 | L17 | L15 | VR3 | TRC 453 |
| VR702 | - | L907 L908 | - | VR504 | VR501 | - | VR502 | - | - | - | - | ??? | TRC 454 |
| R504 | - | C430 L403 L404 | - | R404 | R160 | - | R1411 | - | - | - | - | ??? | TRC 455 |
| VR8 | - | L903 | - | VR6 | VR3 | - | VR5 | - | - | - | - | - | TRC 456 |
| VR6 VR7 | CT7 | VR8 | - | VR12 | VR1 | - | VR3 | - | - | - | - | ??? | TRC 457 |
| VR6 VR7 | CT7 | VR8 | - | VR12 | VR1 | - | VR3 | - | - | - | - | ??? | TRC 458 |
| VR5 | VR6 | VR10 | - | VR7 | VR1 | - | VR2 | - | L16 | L17 | L15 | VR3 | TRC 465 |
| - | - | L104 | - | - | - | - | VR4 | - | - | - | - | ??? | TRC 466 |
| - | - | L102 L104 | - | - | VR6 | - | VR4 | - | - | - | - | CT1 | TRC 467 |
| - | - | T14 | - | - | - | - | - | - | - | - | - | - | TRC 468 |
| VR5 | - | L11 | - | VR4 | VR3 | - | VR2 | - | - | - | - | VC1 | TRC 469 |
| VR4 | - | L6,8 | - | VR3 | VR1 | - | VR2 | - | - | - | - | - | TRC 473 |
| VR4 | - | L8 | - | TXM | VR1 | - | VR2 | - | - | - | - | - | TRC 474 |
| VR By D4 | - | L12 L13 | - | - | - | - | VR By D14 | - | - | - | - | VC By R505 | TRC 477 |
| VR13 | VR4 VR5 | VR14 | - | VR8 | VR10 | - | VR12 | - | - | - | - | ??? | TRC 480 |
