Goody brand Plier and Cutter

PRECISION NIPPERS YN SERIES
PRECISION PLIERS YP SERIES
WIRE STRIPPERS YP SERIES

PRECISION NIPPERS YN SERIES




This line up of nippers has a maximum copper cutting diameter of 1.0 1.3 and 1.6mm.

They are perfect for delicate cutting work.

The flat cutting edges do not place any load on the component body when doing the cutting operation and cutting the precision component lead wires.
NOTE : Only use for cutting copper wire.

 		  This line up of nippers has a maximum copper cutting diameter of 1.6 2.0 and 2.5mm. They are perfect for delicate cutting work.
NOTE : Only use for cutting copper wire.

MODEL
Max. Cut Dia. / mm
Length / mm
YN-10
f1.3
132
YN-12
f1.0
129
YN-17
f1.3 (Thin blade)
132
YN-20
f1.6
132

MODEL
Max. Cut Dia. / mm
Length / mm
YN-11
f1.6
132
YN-18
f2.0
131
YN-19
f2.5
148
MICRO NIPPERS FOR FLAT ICs (FLAT CUTTING SURFACE) Anti-Static

The grip is covered by anti-static material.
This line up of nippers has a maximum copper cutting diameter of 1.0 1.3 and 0.8mm. They are perfect for delicate cutting work.
The flat cutting edges do not place any load on the component body when doing the cutting operation and cutting the precision component lead wires.

NOTE : Only use for cutting wire.



MODEL
Max. Cut Dia. / mm
Length / mm
YN-10AS
f1.3
130
YN-12AS
f1.0
127
YN-13AS
f0.8
120

 轉下頁 Next

主頁 Home


The YN SERIES has a scatter proof clip to prevent the cut wire from scattering.
