| Type | Impedance |
Max Work Frequency | Range | Application | Joining | ||
 |
BNC-Twin | non-constant | 100 MHz | VHF | Point-to-Point// LAN | Bayonet | |
 |
Twinax | non-constant | 200 MHz | VHF | Point-to-Point// LAN | 3/4-20 THD | |
 |
UHF | non-constant | 300 MHz | UHF | Broadcast TV // LAN | 5/8-24 THD | |
 |
TNC-Triax | non-constant | 7/16-28 THD | ||||
 |
Mini-UHF | 50 OHM | 2.5 GHz | S | Telecom// Datacom// Airport Radar// Test Eq. | 5/8-24 THD | |
 |
F | 75 OHM | 3 GHz | S | Telecom// Datacom// Airport Radar// Test Eq. | 3/8-32 THD | |
 |
G | 75 OHM | 3 GHz | S | Telecom// Datacom// Airport Radar// Test Eq. | Push-on | |
 |
BNC | 50 OHM | 4 GHz | S | Telecom// Datacom// Airport Radar// Test Eq. | Bayonet | |
 |
BNC | 75 OHM | 4 GHz | S | Telecom// Datacom// Airport Radar// Test Eq. | Bayonet | |
 |
7/16 | 50 OHM | 7 GHz | C | Satellite Com. Uplink// Power | M29-1.56gTHD | |
 |
C | 50 OHM | 12 GHz | Outdoor appl. Like N + bayonet. | Bayonet | ||
 |
N | 50 OHM | 11 GHz | X | Airborne Radar | 5/8-24 THD | |
 |
ANC | 50 OHM | 11 GHz | X | Airborne Radar | 7/16-28 THD | |
 |
APC 7 | 12.4-18 GHz | Ku | Satellite Com. Downlink// Test Eq.// Doppler Radar. | THD | ||
| Mini | |||||||
 |
1.6/5.6 | 75 OHM | 1 GHz | UHF | Broadcast TV // LAN | M9x0.5 THD | |
 |
FME | 4 GHz | S | Telecom// Datacom// Airport Radar// Test Eq. | |||
 |
SMB-50 Ohm | 50 OHM | 4 GHz | S | Telecom// Datacom// Airport Radar// Test Eq. | Snap-on | |
 |
SMB-75 Ohm/SMZ/BT43 | 75 OHM | 4 GHz | S | Telecom// Datacom// Airport Radar// Test Eq. | Snap-on | |
 |
SMG | 50 OHM | 4 GHz | S | Telecom// Datacom// Airport Radar// Test Eq. | Snap-on | |
| |
SMS | 50 OHM | 4 GHz | S | Telecom// Datacom// Airport Radar// Test Eq. | Snap-on | |
 |
MCX | 50 OHM | 6 GHz | C | Satellite Com. Uplink | Snap-on | |
 |
SMC | 10 GHz | X | Airborne Radar // Navigation Radar | THD | ||
 |
SMA | 50 OHM | 18 (Mil.26.5) GHz | Ku | Satellite Com. Downlink// Test Eq.// Doppler Radar. | 1/4-36 THD | |
 |
APC 3.5 | 26-40 GHz | Ka | Test Eq.// HF Com. | |||
 |
SMP | 50 OHM | 40 GHz | Snap-on | |||
 |
APC 2.4 | 40-100 GHz | mm | Military Aerospace and Electronic Warfare | |||
| Micro | |||||||
 |
1.0/2.3 | 75 OHM | 2 GHz | X | Snap-on | ||
 |
SSMB | 50 OHM | 3 GHz | Snap-on | |||
 |
SSMC | 50 OHM | 6 GHz | 6-40-2A THD | |||
| |
1.0/2.3 | 50 OHM | 10/30 GHz | X | Airborne Radar | Snap-on | |
 |
MMCX | 50 OHM | 6 GHz | C | Satellite Com. Uplink | Snap-on | |
| Reverse Polarity - SMA, BNC, TNC. | |||||||
| Others: |
LEMO ® and Lemo compartibles: Alpine ® ODU ® |
