Burke Jones 2-Meter
This design was originally submitted by Burke Jones. The green highlight shows where Liftroll was hacked to make everything in panel 3 proportionate to that in panel 4. So it’s really a 3-panel wing for ease of construction.
|
area: |
617.10375 |
|
|
|
AR: |
10.04 |
|
|
|
av/mx Cl: |
0.952 |
|
|
|
|
|
|
|
|
|
|
INPUT AREA |
|
|
number |
Span
location |
Cord |
Sweep |
|
1 (Root) |
0 |
9 |
0 |
|
2 |
15 |
8.68 |
0 |
|
3 |
26 |
7.625 |
0 |
|
4 |
32.675 |
6.4625 |
0.5 |
|
5 (Tip) |
39.35 |
5.3 |
1 |
|
AOA: |
10 |
[deg] |
|
