CPU

Intel Pentium 4 in the 478 pin package

Chipset

Northbridge: 82845E MCH
Southbridge: 82801DB ICH4

FSB

400/533Mhz

Form Factor

Bus Speeds

100 - 255MHz

Memory

DDR200/266
3 x 184-pin DDR DIMM Slots Up to 2GB

Ratios

Multiplier Auto Detect
PCI/AGP (33/66 - 50/100)
Host/DRAM (1.5 - 2.0)

Voltages

VCore up to 1.725V
VDimm up to +0.3V
VAgp up to +0.3V

Expansion Slots

1 AGP Slot
6 PCI Slots
1 CNR Slot

Fan Connectors

3 ( 1 CPU, 2 Chassis)

Onboard IDE/SCSI

Dual channel bus master IDE supporting up to 4 IDE devices
Dual Channel UltraDMA133 RAID controller supporting up to 4 IDE devices

Integrated Components

Promise ATA133 w/ RAID chip
VIA VT6306 1394 chip
Intel^ฎ 82562ET LAN PHY
Creative CT5880 5.1-channel audio chip
