Details Production Plan for small buisness (client - serwer database) Fully functional client - server database, designed for small company. Aplication uses free Interbase Server (Borland). Besides necessary accesories, database also provides statistic functions, which can be useful for company's manager. Environment: Borland C++ Builder, Interbase SQL. Production Plan for small buisness [PL] - main window Production Plan for small buisness [PL] - accesories [back to projects] ECGen - ECG signal simulator (using RS232 communication interface) Application uses real ECG samples, collected by holter's device. User can define sampling frequency and transmission parameters. Data blocks are sent through selected COM port. Environment: Microsoft C# .NET ECGen - visualization [back to projects] ECGMonitor - monitoring application for telemedical system Monitoring application is main software component for author's telecardiologic system. Program provides communication between patient and physician and enables consigning ECG probes for analysis (POP3 protocol). Greately developed analysing layer provides tools such as: filtration, autodetection of QRS groups, Etc. Environment: Microsoft C# .NET, SQL Server 2005 ECGMonitor - main window ECGMonitor - window for analyzing ECG signal [back to projects] Merchant Offer for small buisness (calculation sheet) Simple calculation sheet designed for small company. Extended searching and printing tools. Environment: Borland C++ Builder. Merchant Offer for small buisness [PL] - main window [back to projects] Parallel processors structure (design & synchronization) Application tests parallel processors structure, calculates optimal time and cost. Designed for theoretical experiments. Environment: Borland C++ Builder. Parallel processors structure - visualization [back to projects] "INsert" alghoritm for classic jobshop problem Implementation of fast "INsert" algorhitm for classic jobshop NP-complete problem. Environment: Borland C++ Builder. Results given by the alghoritm - visualization [back to projects] Stock-ex-change indexes forseeing (executable script) Script uses neuron - net, which can "forsee" indexes, for next few days. Neurons learn using previous indexes. User may change neuron's activation function, including type of function and parameters. Furthermore, user may define number of epochs and number of neurons in hidden layer. Real / forseen index of WIG20 [back to projects] Tomography image processing (executable script) Script generates back projection from input samples. It can also calculate Radon transformation and generate noises (helpful for experiments). Tomography - back projection [back to projects] Digital / analog filters design (executable script) Simple analog and digital filters designing, parammeters, responses, poles. Elliptic filter design [back to projects] Serial asynchronous receiver design (diagrams) Serial transmitter sends start-bit, message (8 bits), parity-bit, stop-bit. Receiver detects parity errors, errors associated with start-, stop-bit. Leds show receiver's status. Serial asynchronous receiver (main diagram) [back to projects] Cross - lights digital controler (diagrams & hardware implementation) Digital system bases on Xilinx SPARTAN II. Controller offers 3 modes - daily (rush hours), daily (normal), night. It executes pedestrian's demands, and indicates intensified traffic. [back to projects] VCO generator for heterodine device 100-300MHz Designing of voltage controlled oscillator (VCO) for frequency 100-300MHz. Project contains schemas, characteristics, simulations in PSpice and printed circuit board designed in PCB123. Schema of VCO Printed circuit board for VCO [back to projects] Mobile robot "Robocik" Simple mobile robot design. 4 wheel, 2 motors, some electronic circuits and MC68HC811E2 on board. Robot follows the light. Mobile robot "Robocik" [back to projects] Network design (technical project & server configuration) Computer network design (up to 60 computers) with safe Internet connections - technical project. Novell Netware Server configuration. Computer network design - UTP cable instalation Computer network design - idea [back to projects] Control system for greenhouse "Orchidea" PLC devices, sensors and detectors sellection, electrical service design. Irrigation, heating, humidity and lightening control systems. Wiring system Connections schema [back to projects]
