| Weight / Gross Weight: | 2485kg / 4160kg |
| Crew: | 2 men (light truck) 8 men (A/01 infantry carrier) 6 men (A/02 Kommandeurwagen Kfz.21) |
| Engine: | Steyr 3517cc petrol engine OHV air-cooled / 8-cylinder / 85hp at 3000rpm |
| Gearbox: | 4 forward and 1 rear |
| Drivetrain: | Dry plate clutch. 4F1R gearbox. 2-speed transfer box with front axle disconnected. Rear diff lock. |
| Axle Gear Ratio: | 3.98 |
| Brakes: | hydraulic |
| Speed: | Road: 90km/h Cross-Country: 45km/h |
| Range: | Road: 400km Cross-Country: 280km |
| Fuel Capacity: | 100 litres |
| Lenght: | 5.08m |
| Width: | 2.03m |
| Height: | 2.32m |
| Wheelbase: | 3.25m |
| Grund Clearance: | 275mm |
| Tires: | 190-20 or 7.50-20 270-16 for desert use |
| Suspension: | Independent front suspension with torsion bars. Rigid rear axle with semi-elleptic leaf springs. |
| Battery (V A/h): | 12 / 90 |
| Armament: | none |
| Ammo: | none |
| Armor: | none |
 |
 |
