| Wheel arrangement |
4x4 |
| Engine: |
|
| Model |
D-243 |
| Type |
diesel |
| Quantity and lay-out of the cylinders |
4-lined |
| Working volume, l |
4,75 |
| Power, kW (h.p.) |
60 (81) |
| Max torque, Nm (kgs) |
286 (29,0) |
| Gearbox: |
|
| Type |
mechanical |
| Number of gears (forward/backward) |
14/4 |
| Speed, km/h |
|
| Forward |
1,89-33,4 |
| Backward |
3,98-8,97 |
| Rear power take-off shaft: |
|
| Independent I |
570 |
| Independent II |
1000 |
| Synchronous |
3,5 |
| Hydromounted system |
|
| Type |
multipurpose, with separate
units, with power and position adjustment of depth of processing, with mechanic fixation
of mounted unit in transport position. |
| Quantity of outputs for supplementary devices |
6 |
| Tyres dimensions: |
|
| Front |
11,2-20 |
| Rear |
15,5R38 |
| Operation mass, kg |
3900 |
