Aircraft: Douglas 8A-3N

Engine: One Pratt & Whitney R-1830-S3CG Twin Wasp air-cooled radial engine, rated at 1050 hp for takeoff and 900 hp at 12,000 feet.

Maximum speed: 260 mph at 12,000 feet.

Cruising speed: 205 mph.

Landing speed: 66 mph.

Initial climb rate: 1430 feet per minute.

Service ceiling: 29,600 feet,

Normal range: 910 miles.

Wingspan: 47 feet 9 inches

Length: 32 feet 5 inches

Height: 9 feet 9 inches

Wing area: 363 square feet.

Weights: 5508 pounds empty, 7848 pounds gross, 8948 pounds maximum.

Armament: Four wing-mounted 0.30-inch machine guns, plus one flexible 0.30-inch machine gun operated by rear cockpit gunner. Normal bomb load included 20 internally-carried 30-lb bombs and four external 100-lb bombs. Maximum bomb load 1200 pounds.
