Two Brothers C5 oval carbon
fiber slip on
I installed the new C5 oval carbon fiber Two
Brothers slip-on and really like, sounds better than that stock thing. I have seen
some other slip-on for the 929RR and I think this one looks the best so far. The
power from the seat of the pants seems somewhat better, sort of hard to tell with out one
of them cool dynos. There is one here in town so I will try and get a run on
it and see what it is putting out. The directions had me cut of the cone air
diffuser off at the end of the mid-section of the stock pipe, you can see pictures of the
install on the 2000
CBR929RR Picture page. For the most part the install went fine after getting the
air diffuser removed, dermal and hacksaw worked fine for me. I also installed the
new Second Look tank bra, have to save that pretty tank. I like the new tank bra but
it could fit just alittle better.
Second Look seat skins
Installed the cool looking Second Look seat
skins. The installation was fairly easy and only took a few hours. I think
they look much better than the stock ones. You can check out some cool pictures of the new
seat skins here, 2000
CBR929RR Picture page.
Turn signal modifications
I have also modified my stock turn signals,
well sort of. I have a friend that does some painting work and he has developed a
way to paint the stock turn signals and make them look like that are smoked or tinted,
very cool. You can see the pictures here 2000 CBR929RR Picture page.
I have posted his website on the picture page so if you want your turn signals smoked you
can contact him.
N.W.S carbon fiber rear wheel hugger
Installed an N.W.S carbon fiber rear wheel
hugger. I like the look and function of this hugger. I ordered it from N.W.S
and it took about 4 weeks to arrive in the USA, not to bad since the bike is still a new
year model. The installation was very easy and you can see pictures here 2000 CBR929RR Picture page.
The total cost of the hugger was 136.51 British pounds, about $200.00. If you would
like to learn more about the hugger here is a link to N.W.S.
Lockhart-Phillips V2 (double bubble) windscreen
A new windscreen was in order since I really
did not like the stock one, it really did not look that good and was starting to show
small scratches. For alittle more wind protection I went for the Lockhart-Phillips
V2 (double bubble) light smoke. The dark smoke was just to dark to the white and red
for my taste. The new windscreen did improve the wind protection and feels nice out
on the highway. The install was very easy and you can see the pictures here 2000 CBR929RR Picture page.
K&N air filter
The K&N air filter was installed since the
bike was due for a new one. I really wanted to get the bike dynoed before I
installed the K&N filter but was not able to, not enough time and the local shop that
has the dyno was always busy. The installation was very easy but you will want to
make sure you have had the fuel line recall done. I have had the recall done and you
are able to move the tank up enough to allow room for removing the airbox lid. My
riding friend also has a 929RR but did not have the fuel line recall done when we
installed his K&N air filter and there is not much room to get the tank up out of the
way since the fuel line is short. Riding the bike it is really hard to tell if you
get more power but I wanted the filter since I never have to buy another now, just clean,
oil and reinstall. The only thing I really did not like much was the fact the
the filter area on the new K&N is actually smaller than the stock filter area.
You can see the picture of this on the 2000 CBR929RR Picture page.
Front and rear wheel powder coating
I am sure if you own a 929RR/Fireblade you
have noticed that all of them have the same color wheels. I really hated the
graphite/gray color of my wheels so I finally decide to make a change. I removed
both wheels and then had the old tires removed at the local dealer. A good friend of
mine owns a business (ACS, Automotive
Coating Specialist, INC in Tulsa, OK 918-627-5044) that was able to do some
powder coating for me. I took the wheels to him the same day I had the tires removed
and we removed the wheel bears and he went to work. I really has 3 choices on
colors, red,white or black. The red might have looked ok but might not have match
exactly and I also thought the bike had enough red. White was not really an option,
if you have had a bike with white wheels you will know why, they show dirt really
bad. I liked the idea of a shiny black wheel and thought that would be best.
The wheels were powder coated and back to me the next day. I have to say they turned
out great, nice shiny black, perfect. The installation of the wheel bearing was
fairly easy. You will want to make sure that the dust seals did not get damaged when
you removed the bearings, if they did you will want to get some new ones. Once it
was all said and done I had the powder coating done and my 929RR on the road again in
about 2 days, very good. I also could have painted my wheels but I think the powder
coating will be more durable. You can see the pictures of this on the 2000 CBR929RR Picture page.
Galfer stainless steel brake lines
Some new brake lines we in order to try and
get rid of the spongy feel of the brakes. The brakes worked great but just were not
that firm. I installed some Galfer stainless steel lines and was very happy with the
results. The brakes are very firm now and feel great when using them hard. The
installation was not that hard and only took a few hours. You can see the pictures
of this on the 2000
CBR929RR Picture page.
Hyper Pro steering damper
A steering damper was needed after I had
experienced a few head shakes and that was not fun. I decided on the Hyper Pro
steering damper after doing some research and I liked the way it installed the best.
The installation was fairly easy but you will need to make sure you
have a socket large enough to remove and reinstall the steering stem /top triple clamp
nut. I would also suggest some thread lock on the bolt attaching the damper to
the lower frame bracket and the 2 bolts attaching the lower frame bracket and tank to the
frame. I had the screw that attaches the damper to the lower frame bracket
come loose even after I had torqued it to the proper torque. The damper feels good
when riding, it is speed sensitive so at slow speed or movement of the handlebars you do
not feel the damper. I have tested the damper a few times and it does work when the
bike tries to go into a head shake. I did a few small wheelies on a bumpy road and
when I came down I could feel the bike want to head shake but the damper took care of this
right at the time it started. In 2001 I did 3 track days at the Hallett Motor Racing
Circuit and the steering damper really proved its worth then. On some of the slower
corners the front end would get really light and want to skip around when exiting on the
power and sometimes the front end would try and start shaking. When the head shake
would start you would feel the damper go to work and take care of it. This was
definitely a great addition to the CBR and it does help. You can see the pictures of
this on the 2000 CBR929RR
Picture page.
Intuitive frame sliders
I installed the Intuitive frame sliders on my
CBR929RR after I had done some track days in 2001 at Hallett Motor Racing Circuit. I
really loved the track days but felt that the sliders would help if I let the motorcycle
get away in a corner. I have seen other motorcycles go down with and without sliders
and the ones with, were much better off. The installation was very easy and all the
directions were a snap to follow. I would suggest using a torque wrench on the new
bolts that are supplied with the sliders since you are tightening the motor to the frame.
The Honda shop manual for the 929RR lists the correct torque. So far I
have been lucky and have not tested these sliders and hope to keep it that way. You
can see the pictures of this on the 2000 CBR929RR Picture page.
DynoJet Power Commander III
I finally decided to install
the DynoJet Power Commander III on my CBR929RR. I tried to wait and
see what Factor Performance and the Teka would turn out to be but after 2
years I was tired of waiting. The Power Commander was fairly easy to
install and did not take that long. Mounting the Power Commander unit
under the rear rear was easy once I decided how I was going to route the
cables and all. I installed the unit on the side of the under seat
area, not laying flat in the middle of the storage area like the directions
show. I think it is more functional this way and much easier to
install the computer serial cable for loading different maps and doing
adjustment. The connection of the Power Commander to the main
injection harness is not that bad but it is a tight fight if you have
large hands. The installation directions that come with the Power
Commander are pretty good. I loaded the most appropriate map for my
929RR, the M104-003 map. Once on the bike for the first ride I could
tell right off that the Power Commander was worth the money. The
PCIII really helped the throttle response all over and seemed to make the
motor much crisper. The 1st gear on and off throttle response is
much improved. I will try and get the bike on the dyno soon and see
where it is concerning power.
Sigma Sport BC800 bicycle computer
I have been reading about
installing a bicycle computer on the CBR900 email list and really liked
this idea since I plan on changing my gearing soon with a new chain and
sprockets. I did some research on the web about how this was done
and with what bicycle computer. From the reading I did the Sigma
Sport BC800 was the computer of choice. The BC800 has many features:
speed readout, trip distance, clock, odometer, riding time, maximum speed
& average speed. I was able to pick one up at a local bicycle
shop here in Tulsa. The installation was not that hard but did take
me some time to figure out how I want to do it. I wanted the
computer to mount right next to the stock instrument panel so I had to do
some work and built a bracket to mount the BC800. This was fairly
easy to do with some thin aluminum that I cut the bracket from. Once
I had the size I wanted I sanded it all down and put a nice couple of coat
on semi-gloss paint on it to match the stock brackets. Once you
removed the stock instrument cluster you will see that there is a stock
bracket behind it that will allow mounting a thin plate. With the
plate installed I decided how best to mount the computer on the
plate. Remember the BC800 is originally made to fit on a bicycle so
the mounting plate that comes with it is designed for that, it is in a 1/2
circle. I had an old broom handle laying around so I used it to
help with making the mounting easier. I cut the handle in 1/2 and to
make it just fit in the BC800 mounting bracket. Once I had it the size
I wanted I also painted it. So now with the mount pieces made and
painted I put some velcro on the small piece of broom handle and the
aluminum mounting plate. The BC800 comes with 3 thick rubber
bands for installing it on a bicycle, well I took 2 of them and looped them
together and installed them on the back BC800 brackets. Now I was able
to spread the rubber bands apart and slide the BC800 and mounting bracket on
the aluminum mounting bracket that I had previously installed. The
pick up sensor was a little harder to installed, well finding the proper
mounting point was the hard part. I was able to epoxy the sensor to
the very inside section of the left lower fork tube. I also installed
a black zip tie for some insurance. I purchased some round magnets at the
local hardware store and mounted one on the left brake rotor with the epoxy
and another zip tie. I run the wire up around the fork tube and up the
left brake line with some small zip ties. The cable turned out to be
just long enough. The directions that come with the BC800 are pretty
good about telling you how to program the computer once you know your wheel
size (WS) To get your correct wheel size tape a piece of string to the
front tire and roll the bike so that the string wraps around the tire. Be
sure that the string is not inside the tread, cause this will give a smaller
reading. Mark the string where the 2 ends meet. Take the string
and tape off, and measure the length of the string. This needs to be
entered into the computer as millimeters (mm) not inches (in). To convert
inches to millimeters, just divide inches by 0.03937. I do not
remember the wheel size I calculated but will do it again soon since I will
be installing a new front tire. Out on the road the computer would
register about 3 to 4 mph lower than the stock speedo unit once I was about
about 50 mph. The true speed, average speed and top speed numbers are
nice to have. I have been working on a light and will post that once I
get it all worked out. You can see some pictures of this installation
on the 2000 CBR929RR Picture page.
I will post more information as I make other
modifications.
