Toyota Desert Truck Specifications
ENGINE
Type:
Toyota Truck Racing V8, 4 valves per cylinder,
Double Overhead Cam
Displacement: 4.9 liters
Power: 500+ hp at 8200 rpm
Induction: TRD/EFI Technologies
Bore: 3.54 inches
Stroke: 3.75 inches
Compression Ratio: 13:1
Engine Maintenance and Development:
Toyota Racing
Development (TRD)
DRIVE TRAIN
Transmission: 5-speed manual, Hewland Internals
Clutch: Tilton Carbon/Carbon Double Disc
Final Drive: Precision Preparation Inc. - Custom Transaxle
CHASSIS/BODY
Chassis: Chrome-Moly Steel Tube Frame
Body: Carbon/Kevlar shell of Toyota SR5 Xtra Cab
SUSPENSION
Type: 4-wheel fully independent, double-wishbone
Front/Rear: Position sensitive coil spring
Shock Absorbers: Bilstein velocity and position sensitive
WHEELS AND TIRES
Wheels: Ultra Custom Wheels -- 8x17
Tires: BFGoodrich Baja T/A 37x12.5x17R
Brakes:
4 Wheel disc Brembo Calipers, Precision Preparation Inc. - manufactured
rotors
DIMENSIONS
Race Weight: 3,900 pounds
Wheel Base: 120 inches
Overall Length: 188 inches
Overall Width:80 inches
Height: 64 inches
Track Width: 68 inches (Front), 68 inches (Rear)
Fuel Capacity: 43 gallons
|
