Country of manufacture: Portugal.
Size: 180 mm high x 304 mm wide x 70 mm deep.
Weight (excluding batteries): 2.1 kg.
Power supply:
Internal; 6 x C cells, 9V, (radio) 3 x AA cells, 4.5V (clock & memories).
External; 110-127/220-240V AC, 50-60 Hz, or 12V DC.
Battery meter:
Yes, measures battery voltage or external DC supply voltage, even when
radio powered by mains supply, a very thorough approach by the designers.
Tuning method: Digital PLL synthesizer
Tuning options:
Manual tuning
Direct frequency keying
Auto-search, (not SW)
Presets
Metre-band stepping on SW
Memory scan
Wavebands:
FM: 87.5-108 mHz, tuning steps 10kHz (manual tuning) 50 kHz (Auto-search).
AFC: N/A
LW 148-353 kHz, tuning steps 1kHz (manual tuning) 9kHz (auto-search), mode:
AM
MW 513-1611 kHz, tuning steps 1kHz (manual tuning) 9kHz (auto-search),
mode: AM
SW 1612-30000 kHz, tuning steps 1kHz (manual tuning only), modes: AM, SSB
Memories:
24, on any waveband, plus last station memory on each band.
Tuning meter: Yes
Local/DX switch: Yes
Aerials: Ferrite rod for LW & MW, Telescopic for FM & SW
Dial illumination: Yes:
Battery power; press & hold to illuminate LCD display & Battery/Tuning meter, (shared button also displays battery condition)
Mains: permanent while powered, inc. Battery/Tuning meter while set switched on, or on by timer, LCD display only when set switched off, or to Auto. setting but timer not in active time span.
Mono selector: N/A, no stereo facility.
Sockets:
Inputs;
Line-in, (DIN socket shared with line-out).
Aerial.
Telefunken type 2-pole AC in.
DC 12V input.
Outputs;
Line-out, (DIN socket shared with line-in).
3.5mm Headphone (stereo socket wired for mono).
Output power: 2W RMS (battery) 3W RMS (mains)
Speaker: 4 inch dia.
Tone control: Bass, Treble.
Clock/Timer: Yes.
2 x 24 hour clocks, share LCD display with frequency, (use "Time 1" or "Time 2" buttons to display when switched on, permanently displayed when switched off or in "Aux" mode).
1 x event timer, switching on for fixed 1 hour period.
