3-Axle |
 |
2-Axle |
Chassis Dimensions (mm) |
10.6m |
11.3m |
12m |
9.9m |
10.45m |
 |
|
| Wheelbase |
4385 |
4993 |
5700 |
5250 |
5800 |
| Overall Length |
10665 |
11273 |
11856 |
9671 |
10221 |
| Overall Width |
2496 |
2496 |
2496 |
2400 |
2400 |
| Front Overhang |
2286 |
2286 |
2286 |
2271 |
2271 |
| Track (Front) |
2073 |
2073 |
2073 |
2073 |
2073 |
| Track (Rear) |
1493 |
1493 |
1493 |
1493 |
1493 |
| Turning Circle (Kerb) |
15450 |
17070 |
19001 |
15917 |
17915 |
|
Kerb Weights (kg) |
|
|
|
|
| Front Axle |
1710 |
1715 |
1720 |
1700 |
1740 |
| Drive Axle |
3780 |
3790 |
3800 |
1700 |
1740 |
| Drive Axle |
3780 |
3790 |
3800 |
4720 |
4760 |
| Tag |
2900 |
2900 |
2900 |
- |
- |
| Total |
8390 |
8405 |
8420 |
6420 |
6500 |
| Plated Front Axle |
7500 |
7500 |
7500 |
6300 |
6300 |
| Plated Rear Axle |
9500 |
9500 |
9500 |
10500 |
10500 |
| Plated Aux. Axle |
6500 |
6500 |
6500 |
- |
- |
| Plated Gross |
23500 |
23500 |
23500 |
17000 |
17000 |
|
