JVC Non-Linear Editing System
Features
- High picture quality; all 4:2:2 processing video path from input to output and low compression ratios.
- All effects real time (wipes, keys, Genie 3D DVE, Inscriber CG, Etc.)
- Turnkey systemisation; all software, hardware in one unit with JVC Service and support.
- Open Architecture conforming to industry standards for rapid modular upgrade of both hardware and software. (OS: Windows NT 4.0: Buses: PCI and Matrix Movie 2; Microsoft Direct Show; Open DML consortium extended AVI video and audio stream files).
- The system is easily able to perform On-Line or Off-Line editing with scalable MPEG allowing compression ratio from "Lossless" to 30:1.
- EDL import/export
- AVI file import/export
- Inscriber CG( Inscriber Technology, Inc) is combined. Text Animation is available.
- VBS, Component and Serial(option) is acceptable. And analogue audio and AES/EBU is acceptable.
- RS-422 VTR control port x2.
| Discription | Specification |
| GENERAL | |
| Motherboard | IBM PC/AT -compatible PC |
| CPU | Pentimum™3 550 MHz |
| OS | Windows® NT 4.0 English |
| Video CODEC | M-JPEG |
| Audio | 48 kHz 16 bit non compressed |
| Memory | 128 MB |
| HDD | 4 GB for system |
| 2 slots available for removable HDD for AV media. | |
|
FDD
|
3.5 inch 1.44 GB |
| CD-ROM | 1 DRIVE |
| Video control | Direct show® |
| SCSI | LVD (wide), Narrow SCSI |
| Ext. Control | RS-422 VTR control 2ch |
| I/O | |
| Video Input | Composite: BNC |
| Y/C: Din 4 pin | |
| Component: BNC x3 | |
| SDI: BNC (option) | |
| Audio Input | Analog: XLR 3 female x4 |
| AES/EBU: XLR 3 female x2 | |
| REF Input | BNC x2, Loop-through possible |
| Video Output | Composite: BNC |
| Y/C: Din 4 pin | |
| Component: BNC x3 | |
| SDI: BNC (option) | |
| Audio Output | Analog: XLR 3 Male x4 |
| AES/EBU: XLR 3 Male x2 | |
| VGA output | D-sub 15 pin |
