These machine guns were used in the Allied invasion of Normandy.
Browning Automatic Rifle (BAR)
Thompson Submachine Gun
MP-40 Machine Pistol
.30-caliber Air-Cooled Machine gun(M1919A4)
MG .42 Machine Gun
.50-caliber Air-Cooled Machine Gun(M2-HB)
Browning Automatic Rifle (BAR)
Operation
M1918A1:selective fire(fully and semiautomatic);M1918A2;fully automatic
Caliber
.30(7.62 mm)
Muzzle velocity
853.4 mps(2,800 fps)
Capacity
20-round detachable box magazine
Weight
8.33 kg(18.5 lbs)
Overall length
119.4 cm(47 in.)
Rate of fire
550 rounds per minute
Range
up to 80 m(88 yds)
Thompson Submachine Gun
Operation
Selective fire(fully and semiautomatic)
Caliber
.45(11.4 mm)
Muzzle velocity
280 mps(920 fps)
Capacity
50-round drum 20- and 30-round detachable magazine
Weight
4.9 kg(11 lbs)
Overall length
85.6 cm (33.7 in.)
Rate of fire
600 to 725 rounds per minute
Effective range
50 m(55 yds)
MP-40 Machine Pistol
Operation
Fully automatic
Caliber
9 mm(.354 in.)
Muzzle velocity
380 mps(1,247 fps)
Capacity
32-round magazine
Weight
3.97 kg(8.7 lbs)
Overall length
83.2 cm(32.75 in. with stock extended)
Rate of fire
500 rounds per minute
Effective range
100 m(110 yds)
.30-caliber Air-Cooled Machine Gun(M1919A4)
Operation
Fully automatic,air cooled
Caliber
.30(7.62 mm)
Muzzle velocity
853.4 mps(2,800 fps)
Capacity
250-round belt
Weight
18.5 kg(41 lbs) with tripod
Overall length
104.1 cm(41 in.)
Rate of fire
400 to 550 rounds per minute
Effective range
1000 m(1,100 yds)
MG .42 Machine Gun
Operation
Fully automatic
Caliber
7.92 mm(.31 in.)
Muzzle velocity
755 mps(2,478 fps)
Capacity
50-round belt
Weight
11.5 kg(25.3 lbs)
Overall length
121.9 cm (48 in.)
Rate of fire
1,200 rounds per minute
Range
1,000 m(1,100 yds)
.50-caliber Air-Cooled Machine gun(M2-HB)
Operation
Selective fire(fully or semiautomatic),air-cooled
Caliber
.50(12.7 mm)
Muzzle velocity
893 mps(2,930 fps)
Capacity
110-round belt
Weight
57.6 kg(128 lbs) with tripod
Overall length
165.4 cm(65.1 in.)
Rate of fire
450 to 550 rounds per minute
Effective range
1,800 m(1,970 yds)
