Stage-1 Hard Top

Stage-1
Production 1979-1985

Wheelbase
109"

Engine
3528cc V8 petrol twin carb
3.8l 4cyl Diesel; 2623cc 6cyl Petrol R6

Bodies
Station Wagon; Hard Top

History
Also known as the Series III R6, the Stage One name is a reflection of Rover's management investment into the Landrover. The result of this investment was the creation of the flush front Landrover.

A leaf sprung 109" Series III was used as the base vehicle, the 1st cross member was moved forward, the 2nd Cross member removed, the cross member under the gearbox became removable and the cross member behind the transmission was cut away to accommodate the prop shaft. The front grille and the radiator were now moved forward, hence a flat front, the full-time 4WD system was kept.

The Stage One benefited from the development of its luxurious sister, by the incorporation of a Range Rover style diff with constant velocity joints.


Specs Table
Wheelbase 109"
Production 1997-1985
Engine 3.8l Diesel
2.6l Petrol
3.5l V8
Weight 1500kg
Clearance
Wading depth
248mm
500mm
Height
Width
Length
2070mm
1.68m
4.41m
Track
Turning circle
1.33m
14.3m
Gearbox Santana all syncromesh 4 speed
Body
Characteristics
Front flush with wings
Rounded square steel grill
Extended bonnet
Insurance
Groups
5-6
