RIM SIZE (inch) |
PIOLT HOLE DIA |
OFF SET |
NO. BOLT HOLES |
HUB BOLT HOLE DIA. |
BOLT CIRCLE DIA |
THICKNESS |
|
|
RIM |
DISC |
||||||
|
8x3.75 |
Ø64.0+0.5 Ø72.0+0.5 |
- - |
4 5 |
Ø14.5+3 Ø14.5+3 |
102.0 114.3 |
-
|
2.0 2.0 |
|
8x7 |
Ø72.0+0.5 Ø72.0+0.5 |
- - |
4 5 |
Ø14.5+3 Ø14.5+3 |
101.6 114.3 |
|
2.0 2.0 |
|
10x6 |
Ø72.0+0.5 Ø72.0+0.5 |
- - |
4 5 |
Ø14.5+3 Ø14.5+3 |
102.0 114.3 |
|
2.6 2.6 |
|
12x4.0 |
Ø72.0+0.5 Ø84.5+0.5 |
3.0+1.0 3.0+1.0 |
4 5 |
Ø14.5+3 Ø14.5+3 |
102.0 114.3 |
2.6 2.6 |
4.0 4.0 |
|
13x4.5 |
Ø64.0+0.5 Ø84.5+0.5 |
7.5+1.0 7.5+1.0 |
4 5 |
Ø14.5+3 Ø14.5+3 |
102.0 114.3 |
2.8 2.8 |
4.5 4.5 |
|
14x6 |
Ø84.5+0.5 |
3.0+1.0 |
5 |
Ø14.5+3 |
114.3 |
3.2 |
5.0 |
|
14x6DIR PIN |
Ø84.5+0.5 |
3.0+1.0 |
5 |
Ø14.5+3 |
114.3 |
3.2 |
6.0 |
|
15X6 |
Ø84.5+0.5 Ø108.7+0.5 |
9.0+1.0 9.0+1.0 |
5 6 |
Ø14.5+3 Ø14.5+3 |
114.3 139.7 |
3.2 3.2 |
5.0 6.0 |
|
