Feature &
Characteristic：
-
4
Ch. Video input。
-
Resolution
320 x 240 per channel。
-
Display
adjustable 1,2,3 or 4 Per monitor。
-
Playback
adjustable 1, 2,3
or 4 per monitor。
-
Video
Output XVGA。
-
Video
Compression 320 x 240 average 3 ~ 7 Kbyte
。
-
Independent
adjustment for Video contrast, Brightness, Hue。
-
24
group recording mode scheduling。
-
Motion
detection in 10 areas for each channel。
-
Monitoring,
Recording, Searching, Playback, simultaneously。
-
Searching
mode: Time, Date, Camera。
-
OSD
feature: camera labeling, numbers, recording mode, times, HDD
capacity。
-
Password:
System operation, searching, Pan/Tilt/Zoom, Remote surveillance。
-
Backup
media: HDD, DVD, RAM, DAT, CDRW。
-
Video
transformable to AVI format for other multimedia direct playback。
-
BMP
or JPG image format for easy editing & Print out。
-
RS-232
P/T/Z control transmission。
-
Internet
or LAN remote surveillance & emergency warning。
Characteristic & specification
|
|
CPU |
Intel Celeron 1.1G or better |
|
Memory |
SDRAM 128mb |
|
HDD |
40
GB or upgradeable optional |
|
Backup |
3.5” FDD |
|
Compression
system |
M-Jpeg |
|
Compressed size |
320
x 240 : average 3 ~ 7 Kbytes |
|
Resolution |
320
x 240 |
|
Video
input |
4
Channels |
|
Video output |
XVGA
or Video monitor |
|
Recording mode |
Continuous, Motion detection or scheduled recording |
|
Display speed |
NTSC: 8FPS / channel, PAL: 6FPS / channel |
|
Recording speed |
NTSC: 8FPS / channel, PAL: 6FPS / channel |
|
Pan / Tilt / Zoom |
RS-422 / 485 Interface (Option: additional converter CPT-AD485) |
|
Motion Detection |
10
zones per channel adjustable sensitivity |
|
Searching |
Date
& Time, Channel |
|
Watermarking |
Authentication software to prevent manipulation (Optional) |
|
User level |
3
Level (administrator, search user, PTZ/Backup user) |
|
Auto reboot |
Yes |
|
Recording speed setting |
Separate |
|
Dimension |
138
(W) x 349 (D) x 329 (H) , 7400 gr. |
|

|
