The first three files in the Downloads page are directories that have been archived with the UNIX 'tar' command and compresses with 'gzip'. Transfer the files into your cadence working directory. Then use the following string of commands on each file.

gzip -d (filename)

tar xvf (filename)

This should decompress the files and create the proper directories where necessary.

Use the Library Path Editor in the icfb window to link the new directories into the Library Manager. The new libraries are:

pCells

hp14Lib0004

The 'pCells' library contains a modified set of device level schematics and symbols. These are used in creating schematics, extraction, and layout versus schematic. The 'hp14Lib0004' is the actual compiled technology library. Working libraries should be attached to this for proper functionality.

Last modified on: December 9, 1999 by Willem-Jan Ouborg
