F333 SP

Engine:
Longitudinal, mid-mounted 65° V12 derived from a standard production model (F 130)

Bore & Stroke:
85x58.7 mm

Unitary and Total Displacement:
333/3,997 cc



Max. Power Output:
650 bhp at 11,000 rpm

Timing Gear:
5 valves per cylinder, twin overhead camshafts per cylinder bank, titanium valves and connecting rods

Fuel Feed:
Weber-Marelli SPI electronic injection

Lubrication System:
Dry sump, separate oil tank



Transmission:
5.5" four metal plate clutch, transverse, non-synchromesh 5-speed sequential gearbox + reverse, adjustable limited-slip differential

Chassis:
Carbon fibre and aluminum honeycomb

Front Suspension:
F1-derived unequal-length double wishbones, push-rod operated in-board co-axial springs and dampers



Rear Suspension:
F1-derived unequal-length double wishbones, push-rod operated in-board co-axial springs and dampers

Brakes:
Brembo cast-iron discs

Steering:
Right-hand drive, rack and pinion

Cooling System:
Water

Length:
4569 mm



Width:
2000 mm

Height:
1025 mm

Wheelbase and Front/ Rear Track:
2,750/1,660/1,572 mm

Kerb Weight (with water and oil):
862 kg

Front Tyres:
25/11.5 x 17



Rear Tyres:
27.5/14.5 x 17

Fuel Tank:
70 litres, or 100 for 24 hour races

Bodywork:
Modular carbon fibre and Nomex composite

Top Speed:
368 km/h (with longest gearing) 0-100 km/h 3.3 s
